Integrated Power Distribution Cabinet
Compact, High-Efficiency Modular Power for Data Centers.
Integrated Power Distribution Cabinet
Conluxs Integrated Series · 19-Inch Rack Architecture · Modular Precision
Product Overview
The Conluxs Integrated Power Distribution Cabinet is a comprehensive, rack-based solution engineered specifically for modern data centers. By utilizing a standard 19-inch architecture, this system provides bespoke power distribution in close proximity to IT hardware. This configuration significantly minimizes cable run lengths, optimizes facility floor space, and ensures visual consistency across the data center floor. Built with modular precision, our integrated solution guarantees rapid deployment, superior resource utilization, and long-term investment protection.
Target Applications: Data Centers, Server Rooms, IT/Network Closets, Banking Branches, and Telecommunication Base Stations.
Key Technical Features
- Integrated Architecture: Fully modular component ecosystem with exceptional cross-device compatibility.
- Serialized Scalability: Standardized modules allow for simplified, flexible, and high-speed configuration.
- Proximity Power Delivery: Rack-mounted design delivers power directly at the load, reducing transmission loss.
- Enhanced Power Quality: Integrated UPS support reduces conversion stages, ensuring cleaner power delivery to mission-critical IT infrastructure.
- Intelligent Network Management: Real-time digital monitoring with RS-485 interfaces for seamless facility oversight.
Engineering Advantages
| Feature | Specification Details |
|---|---|
| High Integration | Compact, lightweight, modular design for effortless transportation and installation. |
| Adaptive Power | Supports seamless switching between 3-phase 3-wire and 3-phase 4-wire power inputs. |
| ATS Integration | Multi-path input with automatic transfer; optional generator start-up interfaces. |
| 0ms Seamless Transfer | Optional built-in UPS system providing 0ms seamless transition between grid and generator, ensuring zero interruption to critical IT loads. |
| Surge Protection | Integrated B+C class high-performance surge protection for downstream equipment safety. |
| Voltage Precision | Ultra-stable output voltage precision up to ±1% (UPS mode). |
| Harmonic Mitigation | Optional active filters provide clean, interference-free power. |
| DSP Control | Advanced DSP (Digital Signal Processing) for high-efficiency, stable performance with millisecond-level response. |
| Maintenance | Full bypass functionality supports online component replacement without service interruption. |
| Battery Systems | Standard lead-acid maintenance-free; optional LiFePO4 (Lithium Iron Phosphate) support. |
| HMI Interface | 7-inch full-color touchscreen with intuitive graphical visualization. |
| 84 Branch Outputs | Supports up to 84 output branch circuits within a single cabinet for maximum deployment density. |
| Remote Management | Comprehensive remote access, SMS alerts, and mobile App monitoring. |
Ready to Deploy Integrated Power?
Download the complete technical datasheet or contact our sales team for a custom configuration. Our engineering team will follow up within 48 hours.
